ML-80I - ML-80I Installer Rnd in-ceil
|
|
Information
Martin Logan | ML-80i
Specifications
|
Frequency Response |
60–20,000 Hz ±2dB |
|
Recommended Amplifier Power |
20—120 watts per channel |
|
Sensitivity |
90 dB/2.83 volts/meter |
|
Impedance |
8 Ohms. Compatible with 4, 6 or 8 ohm rated amplifiers. Compatible with 4, 6, or 8 Ohm rated amplifiers. |
|
Crossover Frequency |
2500 Hz |
|
High Frequency Transducer |
1" (2.5cm) titanium dome |
|
Low Frequency Transducer |
8" (21cm) mineral-filled polypropylene cone |
|
Inputs |
Spring clip accommodates wire up to 12AWG |
|
Weight |
4.4 lbs. (2 kg) |
|
Cut-Out Dimensions |
9.375" dia. |
|
Projection From Wall Surface |
0.2" (0.5cm) |
|
Depth Behind Wall Surface |
3.8" (9.5 cm) |
