AX800 FBT Dual Channel Power Amplifier 2 x 250W - Power Amplifiers

AX800 FBT Dual Channel Power Amplifier 2 x 250W
AX800 FBT Dual Channel Power Amplifier 2 x 250W at 8 Ohms, 2 x 400W at 4 Ohms, 800W Bridged into 8 Ohms. Class AB. Fan cooled front panel attenuators. 2RU
Price:
NZ$ 1,396.84 including GST

NZ$ 1,214.64 excluding GST


or four payments of $349.21 with
Afterpay Payment Offer Learn More

AX800
Rating:
( 0 reviews )
Purchase Qty:



Tough, reliable, genuinly powerful the AX 800 offers this and is ideal for live sound reinforcement speaker systems in clubs, discos, piano bar, conference halls, houses of worship, sports arenas, schools, theatres, mobile DJ use, recording studio monitors and foreground music reproduction.

2 Ch. Power Amp - 2x400Wrms (4ohm) - 800Wrms (8ohm bridge)

Suitable applications:
Amplification for live sound reinforcement speaker systems in clubs, discos, piano bar, conference halls, houses of worship, sports arenas, schools, theatres, mobile D.J. use, recording studio monitors, foreground music reproduction, etc

Tour tough built, sleek design, impressive specs, excellent cost per watt performance, efficient under any application. With these credentials, FBT proudly presents the new AX series of power amplifiers, the perfect power mates for sound reinforcement speaker systems. The AX series consists in four 2HU rack mount models, from 800 to 3000 watts, all designed with sophisticated power amp circuits for improved quality, stability and reliability, all equipped with Stereo-Parallel-Bridge operation mode, dB sensitivity switch (26-29-32dB), limiter, ground lift, XLR/Jack inputs (plus extra RCA input on AX 800), Speakon/Binding posts outputs.

Both channel driven 8 ohm 1% THD Continous/impulsive: 230/250W
Both channel driven 4 ohm 1% THD Continous/impulsive: 350/400W
Bridge 8ohm 1% THD: 700/800W
Input impedance: 20Kbalanced
Signal to noise ratio S/N: >100dB
Total harmonic dist. (1kHz-4ohm): < 0.03%
Frequency response: 20Hz-40kHz -6dB
Damping Factor: > 400
Class: AB
Maximum power consuption: 1000VA
Power supply voltage: 120 or 230 Vac 50/60Hz
Protections: Short circuit / thermal

Connectors: IN: XLR/Jack - Out: Speakon/Binding post

Net Dimension (WxHxD):
482 x 88 x 290mm
