The 2E10-110-KIT-A includes one 2E10-110-RX EPoC adapter, one 2E10-110-TX EPoC adapter and one bundled 65W@56VDC power adapter.

Perfect for adding a PoE Intercom or camera to an existing bell wire or similar when retrofiting modern IP based devices.

The network connected device (Receiver) plugs into a standard LAN port. The 2 wire cable connects between the Receiver and Transmitter. The Transmitter provides power (PoE) and a LAN connection to the peripheral device.

New Brighton TV & HiFi has used these devices on multiple jobs including one which required a connction for 1x IP iintercom and 3x IP cameras via a PoE splitter with great success.

You don’t have to configure anything, and you only need one EPo2 unit at each end of PoE IP device (PD) & Ethernet Switch port.

In addition to reuse 2-wire cable, the EPo2 is designed to extend PoE range & data rates far beyond 100meters/100 Mbps limits even using 2-wire 26AWG cable.

Interface: 1 x 2E10-110-RX EPoC adapter, 1 x 2E10-110-TX EPoC adapter
Power Input: 100-240VAC
Power Output: 65W@56VDC power adapter (included)
Operating Temp: -20 to 60°C
TAA Compliant, made in Taiwan

Specs (2E10-110-RX)
Interface / Distance
2 Wire Link
2-Pin Terminal Block x1
10/100 Mbps Ethernet
RJ45 x1
Transmission mode
Receiver RX mode
Maximum TX quantity
7
Cable Type
Doorbell wire 18/20/22 AWG
Telephone cable 24/26AWG
UTP/STP cable: 23/24AWG
Bandwidth
600 Mbps

Power Specifications
Power supply
Input: 100-240VAC
Output: 65W@56VDC Power Adapter
Unit Power Consumption
3 watts

Physical Specifications
Dimensions (LxWxH)
85.4 x 47.1 x 23 mm (3.36×1.85×0.91
Weight
0.2 kg (0.44 lb)
Connectors
2P Terminal Blockx1, RJ45 x1, DC Jack x1
Mounting Type
Wall mount

Environmental Specifications
Operating Temperature
-20°C ~ 60°C (-28°F ~ 140°F)
Storage Temperature
-20°C ~ 85°C (-28°F ~ 185°F)
Relative Humidity
5% ~ 95% non-condensing

Certifications
EMC
CE, FCC, VCCI, C-Tick
Safety
EN60950-1

LEDs
LAN
Ethernet status
PWR
Power status
LINK
EPo2 TX device connect status

Specs (2E10-110-TX)
Interface / Distance
2 Wire Link
2-Pin Terminal Block x1
10/100 Mbps Ethernet
PoE PSE RJ45 x1
Transmission mode
Transmitter TX mode
Cable Type
Doorbell wire 18/20/22 AWG
Telephone cable 24/26AWG
UTP/STP cable: 23/24AWG
Bandwidth
600 Mbps

Power Specifications
Power Input
EPo2@50~57VDC
50~57 VDC power adapter
Power Output
PoE
Unit Power Consumption
3 watts

Physical Specifications
Dimensions (LxWxH)
85.4 x 47.1 x 23 mm (3.36×1.85×0.91
Weight
0.2 kg (0.44 lb)
Connectors
2P Terminal Block x1, RJ45 x1,
DC Jack x1, PoE On/Off Switch x1
Mounting Type
Wall mount

Environmental Specifications
Operating Temperature
-20°C ~ 60°C (-28°F ~ 140°F)
Storage Temperature
-20°C ~ 85°C (-28°F ~ 185°F)
Relative Humidity
5% ~ 95% non-condensing

Certifications
EMC
CE, FCC, VCCI, C-Tick

LEDs
LAN
Ethernet status
PWR
Power status
LINK
EPo2 TX device connect status
POE
PoE status
