Onkyo TX8220 2ch 100W @6ohm Streaming Receiver - Onkyo
|
|
Dimensions (WxHxD) 435x149x328mm
or four payments of $199.75
with
Learn More
Information
Universal connectivity meets pure analog amplification in a simple hub that sounds a whole lot better than its modest price suggests. All the essentials are covered with digital audio inputs for TV and BD/DVD player connection, along with an MM phono equalizer, four analog line-level inputs for CD player and everything else.

Specifications
| Power Watts/Ch (6 Ohms 1kHz, 2 Ch Driven, FTC) | 100, 0.10% THD |
| Power Watts/Ch (8 Ohms 20-20kHz, 2 Channels Driven, FTC) | 45, 0.08% THD |
| Dynamic Power | 140 W (3 Ohms, Front) 120 W (4 Ohms, Front) 80 W (8 Ohms, Front) |
| WRAT (Wide Range Amplifier Technology) | ✓ |
| H.C.P.S. (High Current Power Supply) | - |
| Non-Phase-Shift Amp Design | ✓ (for Realistic Sound Imaging) |
| 6 Ohm Capable | ✓ |
| 4 Ohm Capable | ✓ |
| Direct/Pure Mode | ✓/- |
| 384K/32 Bit DACs | - |
| 192K/24 Bit DACs | ✓(PCM1754)) |
| Audio Input/Output | 4/1 |
| Phono Input | ✓ |
| Digital Audio IN (Opt/Coax) | 1/1 |
| Auto Power On When Signal is Detected | - |
| Zone 2 Line Out | - |
| Zone 2 Digital to Analog Audio Conversion | - |
| Speaker A/+B | ✓ |
| Subwoofer Pre-out | ✓ |
| Headphone Jack | ✓ |
| Bluetooth | ✓ (Version 4.1, A2DP/AVRCP) |
| Internet Radio Capable | - |
| Spotify Connect Support | - |
| Streaming Audio From PC / Network | - |
| Hi-Res Streaming Audio Formats | - |
| Supports Onkyo Remote App | - |
| Wireless Network | - |
| USB Input | - |
| AirPlay | - |
| Firmware Updates via Network/USB | ✓ |
| Quick Access BGM Presets | - |
| Number of AM/FM Presets | 40 |
| Preset Station Naming | ✓ |
| Direct Access Tuning | ✓ |
| Automatic/Manual Tuning | ✓ |
| Sleep Timer | ✓ |
| IR Input | - |
| IR Output | - |
| RI-Compatible Remote Control | ✓ |
| Warranty | 2 YEARS |
