DRA-900H

2.2 Ch. 100W 8K AV Receiver with HEOS® Built-in

Enjoy your music and movie collections, including vinyl, CD, Hi-Res, Blu-ray, and even the latest 8K content, all from a two channel system. Plus, with HEOS® Built-in, you can wirelessly stream online music and share it with HEOS-enabled speakers in other rooms.

High-performance two-channel amplifier
Expert sound engineering
Advanced 8K HDMI connection
HEOS® Built-in
Simple, intuitive setup
Built-in Wi-Fi and Bluetooth®

Superb performance

A stereo network receiver seamlessly integrated with the latest AV technologies.

Expertly engineered for all sources

Enjoy your hi-res audio files, vinyl collections, movies, and games with Denon® Hi-Fi sound.

Geared for 8K

Enjoy amazing video quality from the latest 8K technology.

Plenty of power for plenty of devices

HEOS® Built-in

Access streaming music and share with other HEOS speakers.

Premium two-channel Amplifier

Discrete high-current amplifiers deliver up to 100W per channel at 8 ohms.

Built-in Wi-Fi and Bluetooth ®

Easy connectivity for your wireless network or direct music streaming from your smart devices. Use AirPlay to stream Apple Music.

Simple setup

Our award-winning guided setup assistant provides clear, step-by-step instructions to get you started.

Over a century of innovation

Founded in 1910, Denon enables the moments that matter through the relentless pursuit of quality, innovation, and audio performance.

Multichannel Surround

Max. number of processing (preamp) channels 2.1

Sound Enhancements

Discrete Power Amplifier Yes
Pure Direct Yes
Gold Plated RCA Terminals Yes
Compressed Audio Restorer Yes

Network

Media Server Yes
HEOS Wireless Multi-Room Technology Yes
Alexa / Google Voice Assistant / Apple HomePod Yes / Yes / Yes
Lossy Formats: MP3 / WMA / AAC Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV Yes / Yes / Yes
Lossless Formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 Yes / Yes / Yes
DSD Audio Streaming Yes (2.8/5.6MHz)
FLAC HD 192/24 Yes
WAV 192/24 Yes
ALAC 192/24 Yes
Gapless playback Yes (FLAC, WAV, ALAC ,DSD)
AirPlay Audio Streaming Yes (AirPlay2)
Internet Radio Yes (TuneIn)
Spotify Connect Yes (connect)
Pandora Yes
SiriusXM Yes
Other Streaming Services Amazon Music HD/ Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix
Roon Tested Yes
HEOS App Control Yes
Compatible with Remote APP for Smart Phones Denon AVR Remote
Compatible with Remote APP for Tablets Android / iOS / Amazon Kindle
Ethernet Ports Yes
Wi-Fi Yes
Bluetooth Yes

HDMI

HDMI Inputs: Back, Front 6 / No
HDCP2.3 support Yes
HDMI Outputs: Main, Zone 1 / No
HDMI to HDMI Scaling 1080P/4K to 8K
HDMI 2.1: 8K/60 Hz AB / 4K/120 Hz AB Yes / Yes
8K/60Hz AB / 4K/120Hz AB Pass-Through In/Out 3/1 (up to 40Gbps)
HDMI 2.0: 3D / 4K / CEC / ARC / InstaPrevue Yes / Yes / Yes / Yes / No
HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR Yes / Yes / No / Yes / Yes
ALLM (Auto Low Latency Mode) Pass-Through for Gaming Yes
Variable Refresh Rate / Quick Flame Transport / Quick Media Switching Yes / Yes / No
3D Signal Pass-Through Yes
8K Signal Pass-Through, Scaling, GUI Overlay Yes / Yes / Yes
4K Signal Pass-Through / Scaling / GUI Overlay Yes / Yes / Yes
HDMI Pass-Though in Standby Mode Yes
CEC Yes
Audio Return Channel ARC, eARC
Auto LipSync Yes

Multi-room / CI

Multi-Room Zones 2
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Pre-Out No / Yes
IP Control / RS232 Control / Web Control / App Control Yes / No /Yes / Yes
Remote In/Out Yes / No
HDMI Diagnostics Yes

Others

Front Display 1 Line FLD
Graphic User Interface - GUI HD GUI
GUI Languages 3
Setup Assistent Yes
Quick Select Plus, Quick Select Yes / No
Firmware Update by Network / USB Yes / Yes
ECO Mode Yes
Auto Power Off Yes
Sleep Timer Yes

Inputs Outputs

VIDEO
HDMI In/Out 6 / 1
AUDIO
Analog In, Out 2 / No
Phono (MM) In Yes
Digital in: Optical/Coaxial 2 / 1
Multi-Room Out: Analog/Digital 1 / No
Multichannel Pre-out Yes (2.2)
Subwoofer Out 2
OTHER
Speaker Terminal: Gold-Plated Screw / Regular Screw Yes / No
Number of Speaker Terminals 4
Speaker A / B Yes
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB No / No / No / No / Yes
USB Audio / Made for iPod / Made for iPhone Yes / No / No
USB Power Supply on Rear Panel Yes
AM/FM Tuner Yes

Specifications

Number of Power Amps 2
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) 100 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 120 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive) 175 W

General

System Remote Control RC-1259
Power Consumption in W 220W
Power Consumption No-Sound (ECO On / Off) in W 23W/32W
Standby Consumption in W 0.1
CEC Standby Consumption in W 0.5
Network Standby Consumption in W Less than 2.0
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm
( Antenna:Vertical :(W x D x H) in mm)
【 w/o Antenna :(W x D x H) in mm】
17.1× 13.3 × 6
( 17.1 x 13.3 x 8.5)
Weight in LBS 18.3
Weight in LBS (Packaging) 23.1
Power Supply AC 120 V, 60 Hz
Speaker Impedance 4–16Ω/ohms
Pre-Amplifier Section
Input Sensitivity 200 mV
Frequency Response 10 Hz–100 kHz — +1, –3dB (Direct mode)
S/N Ratio 98dB (IHF-A weighted, Direct mode)
FM section
Tuning Frequency Range 87.5–107.9 MHz
AM section
Tuning Frequency Range 520 kHz–1710 kHz
What's in the Box Main unit, remote control, batteries, AM/FM antennas, quick start guide, AC cord
UPC Code 747192140212
